Dolphin Charger PRO Evo3 - 12V - 90A

Dolphin Charger PRO Evo3 — 12V / 90A

The PRO Evo3 is Dolphin Charger's latest generation of high-performance marine battery chargers, engineered for modern electrical systems that demand compact size, high efficiency, and multi-bank charging. At just 9 lbs with 4 independent isolated DC outputs, it delivers the highest power-to-space ratio in its class — and unlike most competitors, it runs at full power even in extreme heat up to 122°F with no derating.

Key Features

Ultra-Compact & Lightweight — 30–60% lighter than the previous generation. The 12V/90A unit weighs under 9 lbs.

4 Independent Isolated DC Outputs — Charge multiple battery banks simultaneously without cross-interference, simplifying complex charging systems.

NMEA 2000 / CAN Communication — Plug-and-play N2K connectivity with latest PGEN certification for integration with modern marine networks.

High-Efficiency DSP Technology — Delivers full rated power at temperatures up to 50°C (122°F) — no derating, a unique capability in this class.

8 Selectable Battery Profiles — Supports Lead Acid, Gel, AGM, and Lithium-Ion with temperature compensation for optimal charging across chemistries.

Ignition Protected — ISO 8846 and SAE J1171 certified for safe use in fuel-vapor environments.

Specifications

Output Voltage: 12V DC

Output Current: 90A

Weight: ~9 lbs

SKU: DOL-99454

UPC: 786142994543

Documentation

Product Brochure (PDF)
